Quality of Service

Create Quota

Instructions

  1. Login as Admin User
  2. Select Cluster Tab
  3. Select Cluster Config Sub-Tab
  4. Select Configuration Settings
  5. Select Quality of Service to expand.
  6. Click Edit on both options and enable.
  7. Click on Save

Instructions

  1. Select Users and Groups
  2. Select Manage Groups Sub-Tab
  3. Click Search
  4. Click Group QoS on Users Actions.
  5. De-select Unlimited for Storage Quota
  6. Enter 10240 in High Limit of Storage Quota (10240 KiB)
  7. Click Save
  8. Logout of Admin user

Test QOS limit

Instructions

  1. Login as the regular user you created earlier. Be sure to select Users as the Group Name

Instructions

  1. Ensure Buckets and Objects Selected
  2. Click Objects Tab
  3. Select “myrf3bucket”
  4. Click Upload File
  5. Upload a 5Mb and 20Mb File
  6. Click Start Upload
  7. Validate that 5Mb File Succeeds but 20Mb file fails.
  8. Upload another 5Mb File
  9. Confirm this 5Mb File upload Fails

Can you explain why the second 5Mb file fails to upload?

Instructions

  1. Login as Admin User
  2. Select User & Groups Tab
  3. Select Manage Groups Sub-Tab
  4. Click Search
  5. Click Group QoS
  6. Select Unlimited for Storage Quota
  7. Click Save

Instructions

  1. Login as User
  2. Ensure Buckets and Objects Selected
  3. Click Objects Tab
  4. Select “myrf3bucket”
  5. Click Upload File
  6. Upload a 20MB File
  7. Click Start Upload
  8. Ensure Upload completes successfully

Rating Plans

Instructions

  1. Login as Admin User
  2. Select Users & Groups Tab
  3. Select Rating Plan Sub-Tab
  4. Click + Add Rating Plan
  5. Type “demo” under ID
  6. Type “Demo-RP” under Name
  7. Choose your Currency
  8. Expand Storage-Size Rates
  9. Click Add 3 times

Instructions

  1. Update Storage Size and Rate as above.
  2. Click Save

Instructions

  1. Navigate to Users & Groups > Manage Users
  2. Select the Users group name then click SEARCH
  3. Click on Edit next to the User
  4. Select demo from the Rating Plan drop down menu
  5. Click Save to apply the new rating plan

Info

You can only generate a bill using Admin API for a month that has already completed. For more information on billing, check the HyperStore documentation under API > Admin API > billing
